STIHL® MSA 220 T - Battery Chainsaw

Power System:

• Power Source: 36V Battery (AP System)
• Battery: AP 300 S included
• Runtime: Up to 40 minutes (AP 300 S)
• Electrical Input: 2.10 kW
• Mechanical Output: 1.7 kW

Weight & Dimensions:

• Powerhead Only: 6.8 lbs (3.1 kg)
• Total Weight (with battery): 12.2 lbs (5.5 kg)
• Recommended Bar Length: 16" (40 cm)

Cutting System:

• Chain: 3/8" STIHL PICCO™ Super
• Oil Capacity: 7.1 oz (210 ml)
• Oilomatic® automatic lubrication

What is the STIHL MSA 220 C-B battery chainsaw?
The STIHL MSA 220 C-B is a professional cordless chainsaw in the STIHL AP Battery System, designed for felling, limbing, firewood and demanding property maintenance.

How powerful is the STIHL MSA 220 C-B?
It has a listed electrical input of 2.10 kW and mechanical output of 1.7 kW.

Who is the STIHL MSA 220 C-B designed for?
It is suited to arborists, landscapers, acreage owners and professionals who want strong cutting performance without gasoline, pull starts or exhaust emissions.

What battery does the STIHL MSA 220 use?
It operates on STIHL 36V AP System batteries, with the AP 300 S listed as the recommended battery.

Is the AP 300 S battery included?
The supplied specifications list an AP 300 S battery as included, although STIHL also offers tool-only and set configurations. Confirm the exact package before purchase.

How long does the STIHL MSA 220 run with an AP 300 S battery?
STIHL lists up to approximately 40 minutes of runtime.

Will actual battery runtime vary?
Yes. Runtime depends on battery condition, wood type, branch or log diameter, chain sharpness, operating style and weather conditions.

What bar length does the STIHL MSA 220 use?
The recommended guide-bar length is 16 inches, or 40 centimetres.

What is the STIHL Light 04 guide bar?
The STIHL Rollomatic Light 04 is a lightweight guide bar designed to improve balance and maneuverability.

What chain does the STIHL MSA 220 use?
The description references a 3/8-inch PICCO PM3 chain, while the specifications list 3/8-inch PICCO Super. The exact chain supplied should be confirmed for the selected configuration.

Can the STIHL MSA 220 cut firewood?
Yes. Its 1.7 kW output and 16-inch bar make it suitable for cutting firewood and moderate-size logs.

Can the MSA 220 be used for tree felling?
Yes. It is designed for suitable felling and limbing work within the capacity of its bar and chain.

Does the MSA 220 have a felling sight?
Yes. A raised and printed felling stripe helps the operator aim the intended felling direction.

What type of motor does the MSA 220 use?
It uses a brushless electric motor designed for fast acceleration, efficiency and low maintenance.

Does the MSA 220 maintain strong power while cutting?
Its brushless motor is designed to provide responsive acceleration and consistent cutting performance under load.

Does the STIHL MSA 220 have variable speed?
Yes. A variable-speed trigger allows the operator to control chain speed for different cutting tasks.

Does the MSA 220 have tool-free chain adjustment?
Yes. The STIHL Quick Chain Adjuster allows chain tension to be changed without separate tools.

Does the STIHL MSA 220 require bar and chain oil?
Yes. It uses an automatic Oilomatic lubrication system.

How much chain oil does the MSA 220 hold?
The oil tank holds approximately 7.1 oz, or 210 ml.

What is the STIHL Ematic lubrication system?
The Ematic guide bar and Oilomatic chain direct oil to key contact points, helping reduce unnecessary oil consumption.

How much oil can the Ematic system save?
STIHL states that it can reduce bar-oil consumption by up to 50% compared with conventional lubrication methods.

What safety features does the STIHL MSA 220 include?
It includes a throttle-trigger interlock and STIHL Quickstop chain brake.

What does the STIHL Quickstop chain brake do?
It is designed to stop the chain rapidly when activated manually or by inertia during certain kickback situations.

Is the STIHL MSA 220 weather resistant?
Yes. It has an IPX4 rating for protection against splashing water.

Can the MSA 220 be used in wet conditions?
Its IPX4 construction provides splash protection, but it should still be operated and stored according to STIHL’s wet-weather instructions.

How much does the STIHL MSA 220 weigh?
The powerhead weighs approximately 6.8 lb, or 3.1 kg, without a battery.

How much does it weigh with the AP 300 S battery?
The listed total weight is approximately 12.2 lb, or 5.5 kg.

Is the STIHL MSA 220 comfortable to use?
Yes. Its lightweight guide bar, balanced design and rubberized soft-touch handle help improve comfort and control.

Is the MSA 220 quieter than a gas chainsaw?
Yes. It operates with less noise and produces no direct exhaust emissions.

Does the STIHL MSA 220 require fuel mixing?
No. It runs entirely on rechargeable AP System batteries.

What maintenance does the MSA 220 require?
Routine maintenance includes sharpening and tensioning the chain, filling the oil tank, cleaning the guide bar and inspecting the chain brake and sprocket area.

Is the MSA 220 easier to maintain than a gas chainsaw?
Yes. It does not require spark plugs, carburetor adjustments, fuel filters or gasoline storage.

What are the main benefits of the STIHL MSA 220 C-B?
Its main benefits include professional cordless power, a lightweight 16-inch setup, tool-free chain adjustment, variable speed, IPX4 construction and up to 40 minutes of runtime with an AP 300 S battery.

Where can I buy the STIHL MSA 220 C-B battery chainsaw in Canada?
The STIHL MSA 220 C-B battery chainsaw is available in store from Arns Equipment in Calgary or online across Canada at arns.ca.
